DL501 (DSG) TCU Tune | Audi B8/B8.5 S4, S5 | 034Motorsport

Overview

034Motorsport's Dynamic+ DSG Software Upgrade unlocks the full potential of the DL501 7-Speed S-tronic transmission found in B8/B8.5 Audi S4 and S5 models. Flashed directly through your vehicle's OBD-II port, 034Motorsport's proprietary calibrations for the DL501 TCU safely and effectively raise the factory transmission's RPM limiter, allowing your car to make full use of Stage 1/2 Performance ECU Software. Performance DSG Software also increases shift speed and optimizes the shift points in Drive and Sport modes for better performance and drivability. The result is a noticeable improvement in acceleration, without any sacrifice in comfort or reliability.

034Motorsport's DL501 Performance Software was developed entirely in-house on 034Motorsport's Development B8 Audi S4, then refined on multiple enthusiast-owned B8/B8.5 S4/S5 vehicles before release. In addition, End User Flashing allows Dynamic+ Performance Software customers to receive and install software updates and revisions, flash back to stock, or upgrade to the next stage of performance software for their vehicle.

Details

Unlock the full capability of your DL501 S tronic transmission with 034Motorsport Performance DSG Software for the B8/B8.5 Audi S4 and S5. Developed entirely in-house and validated on both development and enthusiast-owned vehicles, this transmission calibration is designed to complement Stage 1 and Stage 2 ECU tuning by raising the factory RPM limit, increasing shift speed, and optimizing shift behavior. Flashed directly through the factory OBD-II port, Performance DSG Software delivers faster acceleration, improved drivability, and enhanced transmission performance without compromising comfort or reliability.

TCU Features

Transmission Calibration

034Motorsport recalibrates the DL501 transmission to maximize the available powerband while improving overall transmission behavior. A raised transmission RPM limit allows the engine to remain in its optimal power range, while optimized shift logic and increased clutch clamping pressure improve power transfer and overall performance.

Shift Performance

Dynamic shift mapping delivers quicker gear changes and revised Drive and Sport mode shift schedules for stronger acceleration and improved responsiveness. Manual mode is also enhanced by disabling kickdown, giving the driver complete control over gear selection.

Launch Control Optimization

Performance DSG Software introduces user-selectable 4-step Launch Control, allowing drivers to choose from 3,000 RPM, 3,500 RPM, 4,500 RPM, or 5,000 RPM launch settings to better match available traction and vehicle setup. The factory Launch Control counter limit is also increased from 200 to 2,000 activations.

OEM+ Features

Performance DSG Software includes several enhancements designed to improve both daily driving and spirited performance:

• Raised transmission RPM limit to 7,200 RPM
• Optimized Drive and Sport mode shift schedules
• Increased DSG clutch clamping pressure
• Faster shift speeds
• Manual mode kickdown disabled
• User-selectable 4-step Launch Control
• Launch Control counter increased from 200 to 2,000
• Flashes directly through the factory OBD-II port with no TCU removal required

Compatibility Notes

• Fits B8 Audi S4
• Fits B8.5 Audi S4
• Fits B8 Audi S5
• Fits B8.5 Audi S5
• DL501 7-Speed S tronic transmission
• Designed to complement 034Motorsport Stage 1 and Stage 2 ECU Tuning
• Flashes directly through the factory OBD-II port

Important Notes

• The raised 7,200 RPM transmission limit is intended for use with compatible Stage 1 and Stage 2 ECU calibrations that also support the increased engine rev limit.
• Launch Control offers four selectable RPM settings (3,000, 3,500, 4,500, and 5,000 RPM) to accommodate varying tire and track conditions.
• The factory Launch Control activation counter is increased from 200 to 2,000, making the software better suited for frequent performance driving or track use.
• Manual mode kickdown is disabled, allowing complete driver control during spirited driving.
