034Motorsport B7 Audi A4 2.0T FSI Performance Software

Overview

034Motorsport Performance Software is now available for B7 Audi A4 models equipped with the EA113 2.0T FSI Longitudinal engine!

Stock: 205 HP / 202 TQ (91 Octane)
Stage 1: 246 HP / 287 TQ (91 Octane)
Stage 2: Figures TBD, File Available to Flash!
K04Turbo: 303 HP / 317 TQ (91 Octane)

Details

Unlock the performance potential of your B7 Audi A4 with 034Motorsport Performance Software for the longitudinal EA113 2.0T FSI engine. Developed entirely in-house and refined on multiple enthusiast-owned vehicles, the calibration delivers significant gains in horsepower, torque, throttle response, and overall drivability while maintaining OEM-level reliability. Flashed directly through the factory OBD-II port, the software provides a straightforward performance upgrade for both stock and modified vehicles.

ECU Features

Power & Performance

034Motorsport Performance Software increases boost pressure while optimizing ignition timing, fueling, and throttle mapping to maximize the performance of the EA113 2.0T FSI engine. A raised 7,100 RPM rev limit extends the usable powerband for improved acceleration and stronger top-end performance, while refined throttle mapping delivers quicker response and improved pedal precision.

Engine Protection

Each calibration is engineered to safely increase performance while maintaining OEM-like drivability and reliability. Extensive street and track testing helps ensure consistent power delivery across a wide range of driving conditions.

Fuel System Optimization

Calibrations are available for 91 octane, 93 octane, 100 octane, and 104 octane fuel, allowing owners to choose the appropriate file based on available fuel and performance goals. Higher-performance calibrations are designed to support upgraded fueling components where required.

OEM+ Features

034Motorsport Performance Software includes several enhancements designed to improve both performance and drivability:

• Raised 7,100 RPM rev limit
• Refined throttle mapping for improved response and pedal precision
• Speed limiter removed
• Track-tested and street-refined calibrations
• Flashing through the factory OBD-II port with no ECU removal required

Fuel & Hardware Requirements

• Stage 1: No hardware required (performance intercooler recommended)
• Stage 2: Requires a high-flow catalytic converter and high-flow turbo inlet hose (performance intercooler recommended)
• Stage 2+: Requires an upgraded HPFP piston kit, high-flow catalytic converter, high-flow turbo inlet hose, and performance intercooler
• K04: Requires a K04 turbocharger, 150 Bar PRV, Audi S3 injectors, 3-Bar MAP sensor, upgraded HPFP piston kit, high-flow catalytic converter, and performance intercooler
• Available in 91 octane, 93 octane, 100 octane, and 104 octane calibrations

Compatibility Notes

• Fits Audi B7 A4
• EA113 2.0T FSI Longitudinal engine
• Bosch MED9 ECU
• Supports Stage 1, Stage 2, Stage 2+, and K04 ECU calibrations
• Flashes directly through the factory OBD-II port

Important Notes

• Stage 2 and Stage 2+ calibration details are available directly from 034Motorsport.
• A performance intercooler is recommended for all stages to maintain consistent performance.
• K04 calibration requires the complete supporting hardware package, including a K04 turbocharger, 150 Bar PRV, Audi S3 injectors, 3-Bar MAP sensor, upgraded HPFP piston kit, and supporting airflow modifications.
• All calibrations feature a raised 7,100 RPM rev limit and are validated through both street and track testing for reliable performance.
